JVC GVLS2WE LIVE STREAMING PTZ CAMERA (PAL) NOT FOR USE IN USA

Product Highlights

1/2.3 Back-Illuminated CMOS Image Sensor

Full HD 1920x1080 Streaming

SD Slot for Full HD Recording

Optical 10x Zoom

Live Monitoring and Remote Operation

Dual Output Streams

Ultra-Quiet Pan/Tilt/Zoom Operation

Wi-Fi Compatibility

The GV-LS2WE Live Streaming PTZ Camera (PAL) is a live-streaming camera with video output, compatible with European broadcast standards. It includes a removable high-speed ultra-quiet pantilter cradle, and can also be remotely controllable via tablet, smartphone, or PC. This camera combines the quality offered by a full-fledged camcorder with the unmanned capabilities of a high-end security camera, and rolls these features into a compact package with Wi-Fi wireless communication and remote controllability.

At the heart of the GV-LS2WE is a 1/2.3" 12.4 megapixel back-illuminated CMOS sensor, and JVC's FALCONBRID high-speed image processing engine. This allows Full HD quality to be maintained even when using electronic image stabilization and pan/tilt. The camera offers 10x optical zoom for high-quality close-ups and for streaming images and sound from live events as it allows the camera to remain unobtrusive.

With the GV-LS2WE you can record your footage in HD on available SD media cards or stream in HD. The camera features dual-stream output allowing you to record and stream at the same time, although only one stream can be in HD. The camera features control via a web browser interface, and you can also monitor and control the camera via the JVC Cam app on a smartphone or tablet.

Camera


The camera features a 12.4 MP back-illuminated CMOS sensor, for improved low-light sensitivity, and an f1.2-2.4 10x optical zoom lens. The FALCONBRID processor provides 16x dynamic and 200x digital zoom.

Audio

The camera features a built-in stereo microphone and a MIC input for an external microphone.

Wireless & Wired Control

The camera features an Ethernet connection that allows you to control the camera using a web browser interface across a network.

The camera also features Wi-Fi connectivity, so you can monitor and control the camera using select Android or IOS devices and the downloadable JVC Cam app.

The camera can connect to an available Wi-Fi router for multi-camera control of up to four live-streaming cameras.

Dual Streams

You can stream HD over Wi-Fi or the Ethernet connection at up to 5Mb/s. The dual stream capability provides up to two output streams (only one in HD) that you can record and stream simultaneously.

Pan Tilt Cradle

Quick & Quiet Pan/Tilt/Zoom

the pan tilt cradle uses direct-drive motors to provide near-silent panning/tilting, with a movement range of ±150° laterally and -30° to +40° vertically.

Sensor

Sensor   Size: 1/2.3" CMOS

MegaPixels: 12.4

Effective Pixels: 2,070,000 to 5,400,000 (DIS: OFF, dynamic zoom: ON)

Min. Illumination              10 lux: Gain Up on

1 lux: Gain Up on, Auto Slow-Shutter

Optics

Focal Length       3.76 to 37.6mm

35mm Equivalent Focal Length    29.5 to 476mm Dynamic Zoom ON

29.5 to 407mm Dynamic Zoom OFF

Maximum Aperture          1.2 to 2.8

Zoom     Optical: 10x

Dynamic: 16x

Digital: 200x

Recording

System PAL

Media    SD/SDHC/SDXC

Video Format     High Definition

AVCHD (MPEG 4)

Video: AVC/H.264

Audio: Dolby Digital 2ch

Data Rate            UXP: 1920 x 1080, 24 Mb/s

XP: 1920 x 1080, 17 Mb/s

SP: 1920 x 1080, 12 Mb/s EP: 1920 x 1080, 4.8 Mb/s

Recording Time SDXC 64GB

UXP: 5 hr 40 min

XP: 8 hr 10 min

SP: 11 hr 30 min

EP: 28 hr 50 min

Aspect Ratio       16:9

Audio Format     AAC

2 Channels

Sampling Frequency         48.0 kHz

Audio Data Rate               256 kb/s

Stream Output

Format 1              Stream 1

Stream 1

Video: JPEG (640 x 360)

Audio: LPCM 16 kHz, 16-bit 1 ch

Stream 2

None

Format 2              Stream 1

MPEG 2 TS

Video: H.264 Main Profile (720 x 576)

Audio: AAC 48 kHz, 16-bit 2 ch

Stream 2

Video: JPEG (640 x 360)

Audio: LPCM 16 kHz, 16-bit 2 ch

Format 3              Stream 1

MPEG 2 TS

Video: H.264 High Profile (71920 x 1080)

Audio: AAC 48 kHz, 16-bit 2 ch

Stream 2

Video: JPEG (640 x 360)

Audio: LPCM 16 kHz, 16-bit 2 ch

Features

Image Stabilization          Digital

Shutter Speed     Not Specified By Manufacturer

White Balance Modes     Auto

Cloudy

Fine

Halogen

Manual

Built-In Microphone         Yes

Built-in Light/Flash           Light: Yes

Flash: No

Network Connectivity     Wired: 10Base-T/100Base-TX

WiFi: 802.11 b/g/n (2.4 GHz)

Tripod Mount     1/4"-20

Input/Output Connectors

Inputs    1 x 1/8" (3.5 mm) Stereo Mini for External Mic

Outputs                AV Output Connector

Video: 1.0 V (p-p), 75?

Audio: 218 mV (rms), 1?

Headphone Jack               No

General

System Requirements      OS

Windows 7

Processor

Core 2 Quad 2.66 GHz or better

Ram

2GB

Power Adapter   100-240VAC, 50/60 Hz

Power Consumption        Using Battery: 3.6VDC

Using AC Adapter: 12VDC

5.6W when using pantilter

Operating Temperature 32 to 104°:F (0 to 40°C)

Storage Temperature      -4 to 122°F (-20 to 50°C)

Relative Humidity             35 to 80%

Dimensions (W x H x D)   Camera: 2.9 x 1.9 x 3.5" (73 x 48 x 90 mm)

Pantilter: 5 x 4.4 x 4.3" (128 x 113 x 108 mm)

Weight Camera: 0.5 lb (226 g)

Pantilter: 1.4 lb (635 g)

VC GV-LS2WE Live Streaming PTZ Camera (PAL)

Pantilter

AC Adapter

AC Cord

Conversion Cable

LAN Cable

Rear Cover

PC Software

•             This is a "PAL" product and CANNOT be used in the USA. It is designed for use with video products built to PAL TV standards.
